Uno.Cupertino

Uno Cupertino is an add-on package that lets you apply Cupertino - Human Interface Guideline styling to your application with a few lines of code.

Getting Started

Note

As of Uno Platform 4.7, the solution template of an Uno app has changed. There is no longer a Shared project (.shproj), it has been replaced with a regular cross-platform library containing all user code files, referred to as the App Code Library project. This also implies that package references can be included in a single location without the previous need to include those in all project heads.

Creating a new project with Uno.Cupertino installed from command-line

1. Install dotnet new templates with:

   dotnet new install Uno.Templates


2. Create a new application with:

   dotnet new unoapp -o AppName -theme cupertino


Installing Uno.Cupertino in existing project that uses class library

1. In the Solution Explorer panel, right-click on your app's App Code Library project (PROJECT_NAME.csproj) and select Manage NuGet Packages...

2. Install the Uno.Cupertino.WinUI

3. Add the following Cupertino resources AppResources.xaml:

   <ResourceDictionary>
       <ResourceDictionary.MergedDictionaries>

       <!-- Load Uno.Cupertino resources -->
       <CupertinoColors xmlns="using:Uno.Cupertino" />
       <CupertinoFonts xmlns="using:Uno.Cupertino" />
       <CupertinoResources xmlns="using:Uno.Cupertino" />

       </ResourceDictionary.MergedDictionaries>
   </ResourceDictionary>


Installing Uno.Cupertino on previous versions of Uno Platform

If your application is based on the older solution template that includes a shared project (.shproj), follow these steps:

1. Open an existing Uno project

2. In the Solution Explorer panel, right-click on your solution name and select Manage NuGet Packages for Solution .... Choose either:

   • The Uno.Cupertino package when targetting Xamarin/UWP
   • The Uno.Cupertino.WinUI package when targetting net6.0+/WinUI

3. Select the following projects for installation:

   • PROJECT_NAME.Wasm.csproj
   • PROJECT_NAME.Mobile.csproj (or PROJECT_NAME.iOS.csproj, PROJECT_NAME.Droid.csproj, and PROJECT_NAME.macOS.csproj if you have an existing project)
   • PROJECT_NAME.Skia.Gtk.csproj
   • PROJECT_NAME.Skia.WPF.csproj
   • PROJECT_NAME.Windows.csproj (or PROJECT_NAME.UWP.csproj for existing projects)

4. Add the following resources inside App.xaml:

   <Application ...>
       <Application.Resources>
           <ResourceDictionary>
               <ResourceDictionary.MergedDictionaries>

                   <!-- Load WinUI resources -->
                   <XamlControlsResources xmlns="using:Microsoft.UI.Xaml.Controls" />

                   <!-- Load Uno.Cupertino resources -->
                   <CupertinoColors xmlns="using:Uno.Cupertino" />
                   <CupertinoFonts xmlns="using:Uno.Cupertino" />
                   <CupertinoResources xmlns="using:Uno.Cupertino" />

                   <!-- Load custom application resources -->
                   <!-- ... -->

               </ResourceDictionary.MergedDictionaries>
           </ResourceDictionary>
       </Application.Resources>
   </Application>


Customization

Customize Color Palette

1. In the application's App Code Library project (PROJECT_NAME.csproj), add a new Resource Dictionary named CupertinoColorsOverride.xaml

2. Save the new override file within the App Code Library, for example, under Style/Application.

3. Replace the content with:

   <ResourceDictionary xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
                       xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml">
       <ResourceDictionary.ThemeDictionaries>

           <!-- Light Theme -->
           <ResourceDictionary x:Key="Light">
               <!-- Override CupertinoBlueBrush -->
               <Color x:Key="CupertinoBlueBrush">#6750A4</Color>

               <!-- Add more overrides here -->
               <!-- ... -->
           </ResourceDictionary>

           <!-- Dark Theme -->
           <ResourceDictionary x:Key="Dark">
               <!-- Override CupertinoBlueBrush -->
               <Color x:Key="CupertinoBlueBrush">#D0BCFF</Color>

               <!-- Add more overrides here -->
               <!-- ... -->
           </ResourceDictionary>

       </ResourceDictionary.ThemeDictionaries>
   </ResourceDictionary>


4. In AppResources.xaml, update <CupertinoColors /> with the override from the previous steps:

   <CupertinoColors xmlns="using:Uno.Cupertino"
                    OverrideSource="ms-appx:///PROJECT_NAME/Style/Application/CupertinoColorsOverride.xaml" />


Change Default Font

By default, Uno.Cupertino comes pre-packaged with the SF Pro FontFamily and automatically includes them in your application. Upon installation of the Uno.Cupertino package, you will have a CupertinoFontFamily resource available.

If you would like Uno.Cupertino to use a different font, you can override the default FontFamily following these steps:

1. Add the custom font following Custom Fonts documentation.

2. In the application's App Code Library project (PROJECT_NAME.csproj), add a new Resource Dictionary named CupertinoFontsOverride.xaml.

3. Save the new override file within the App Code Library, for example, under Style/Application.

4. Assuming the font file has been placed in the App Code Library within, for example, a directory such as Assets/Fonts/MyCustomFont.ttf, your override file would look like the following:

   <ResourceDictionary xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
                       xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml">

       <FontFamily x:Key="CupertinoFontFamily">ms-appx:///PROJECT_NAME/Assets/Fonts/MyCustomFont.ttf</FontFamily>

   </ResourceDictionary>


5. In AppResources.xaml, update <CupertinoFonts /> with the override from the previous steps:

   <CupertinoFonts xmlns="using:Uno.Cupertino"
                   OverrideSource="ms-appx:///PROJECT_NAME/Style/Application/CupertinoFontsOverride.xaml" />
